Charactristic

• Support 4 HDMI inputs, 2 HDMI2.0, 2 HDMI1.4, up to 4K60HZ, backward compatibility

• Supports up to 16 outputs, the output resolution supports 1024*768@60HZ, 1280*800@60HZ, 1280*720@60HZ, 1920*1080@60HZ, 1920*1200@60HZ (splicing), the output resolution can be switched

• Card-type splicing and matrix all-in-one machine, one key to realize free switching

• Splicing mode supports custom MxN splicing

• Support the 180-degree rotation function of any display unit image, and support the upper LCD screen to reverse

• Edge shielding function, splicing mode supports horizontal and vertical splicing adjustment

• Matrix mode supports seamless switching function

• Matrix mode supports any output 4 screen split display

• Support remote control, RS232, TCP-IP (customized), chassis button control

• Standard 3U chassis, can be directly installed in the standard cabinet

Technology

1. Name

   HDMI immobilization matrix

2. input interface

   4 HDMI inputs , 1DP Input

3. Resolution

   HDMI supports a maximum resolution of 3840*2160@60HZ, which is backward compatible

4. Output

   4 HDMI Output

5. Output Interface

   2 to 16 HDMI port outputs can be customized to support simultaneous audio and video output 1 3.5mm audio left and right channel stereo for connecting stereo speakers

6. Output resolution

   1024*768@60HZ，1280*800@60HZ，1280*720@60HZ，1920*1080@60HZ，1920*1200@60HZ，Resolution can be switched

Routine

1. Color depth

   24bit, 16.77 million colors

2. Control method

   Chassis buttons, remote control, RS232, TCP-IP

3. Input voltage

   100 to 240V AC voltage

4. Display mode

   customized 2x2,3x3,4x4,3x4,2x3,2x4,2x5,2x6、etc .

5. Product Size（3U）

   440mm(long)x310mm(width)x133mm(high)

6. Product Weight

   7.5KG

7. Power consumption

   Max 70W
